Packing Details / Spool Details

SPOOLS TYPE P.P./ABS	FLANGE DIA mm A	BARREL DIA mm B	TRAVERSE WIDTH mm C	OVERALL WIDTH mm D	BORE DIA mm E	WEIGHT CAPACITY kg.
DIN-125	125	80	100	125	16	2.9
DIN-160	160	100	128	160	22/36	6.0
DIN-200	200	125	160	200	22/36	10.0
DIN-250	250	160	160	200	22/36	18.0
DIN-355	355	224	160	200	36 127	42.0
DIN-400	400	250	280	320	127	90.0
SPC-270	270	160	160	200	35	23.0
